| VGA+USB Digital Camera (BVUC-501) |
Product Description:
Clear images through the whole range of the FOV. There is no uncomfortable under long time viewing and easy to produce eyestrain; Ergonomic design, the angle of binocular tube is adjustable to avoid fatigue and injury to users; All components adopt modular design, the modular design is easy and flexible combination based on users requirements; With the vast majority of the existing general-purpose microscope accessories, reduce the use of cost and ease to upgrading for the user; Widely used in teaching, research, and electronic testing and assembly industry.
Product Parameters:
|
Image Sensor |
2.0M, 1/3'' CMOS |
|
Resolution |
1600x1200 |
|
VGA(RGB) |
720P/1024×768/1280×1024/1366×768 @ 60HZ |
|
USB |
USB2.0, 800X600,1600X1200 |
|
Frame Rate |
10-15fps |
|
Definition |
up to 800 lines(horizontal) |
|
Shell |
metal |
|
Lens Mount |
standard C mount |
|
White Balance |
automatic |
|
Brightness Adjustment |
automatic |
|
Color |
color/grayscale |
|
Negative |
support |
|
Image |
up/down/left/right |
|
Image Freeze |
support |
|
Language of OSD |
English/Chinese |
|
Image Digital Zoom |
support 10X digital zoom |
|
Image Storage |
support, up to 24 images according to differences of resolution (512M DDR) |
|
Image Contrast |
support static images and dynamic image 1/2 screen contrast |
|
Edge Enhancement |
support |
|
Contrast |
support |
|
Chroma |
support |
|
Cross Line |
multicolor 2 horizontal lines and 2 vertical lines, moveable, on/off depends on need |
|
Digital Noise Reduction |
support |
|
